Research Article
Print
Research Article
Descriptions of two new species of Culicoides Latreille from Sundarbans, India with an adult key to the ornatus species group of the Oriental region (Diptera, Ceratopogonidae)
expand article infoSomnath Chatterjee, Gouri Sankar Pal, Niladri Hazra
‡ The University of Burdwan, Burdwan, India
Open Access

Abstract

Two new species of biting midges, Culicoides cornatus sp. nov. and Culicoides pileus sp. nov. are described based on adults. The new species are compared to their congeners with close similarity. All specimens were collected from the Indian Sundarban Mangrove Forests, few specimens were mounted in glass slides and few were prepared for SEM study. Total 78 species under the genus Culicoides Latreille including the two new ones (6 species from ornatus species group) are described from India. An adult key of the ornatus species group from the Oriental Region is provided.

Key Words

Adult Key, India, New species, ornatus group, Sundarbans, Taxonomy

Introduction

Culicoides Latreille, 1809 is one of the most species rich genera of the family Ceratopogonidae with approximately 1368 valid species, 32 subgenera, 38 species groups, and 176 unplaced species described worldwide (Borkent and Dominiak 2020); so far 76 species have been reported from India (Chatterjee et al. 2020). Most female members of this genus are haematophagous and many species act as important vectors of pathogenic viruses, protozoans and filarial nematodes (Mellor et al. 2000; Borkent 2005). These midges are of great concern because they transmit bluetongue (BT), Akabane and other viruses that cause disease in sheep, cattle and wild ruminants (Kettle 1977; Linley et al. 1983). The outbreak of the BT disease in Tamil Nadu (India) and its occurrence in many parts of India over the last few decades has affected millions of sheep and goats and other livestock (Ilango 2006). Immature stages of this genus can be found in a variety of aquatic or semi aquatic habitats, including tree holes, ponds, marshes, streams, various muddy and saturated organic materials, damp or rotting vegetation, and manure (Kettle and Lawson 1952; Jamnback 1965; Borkent 2014; Shults and Borkent 2018).

The ornatus species group of this genus comprises of 33 species worldwide (Nandi et al. 2013; Borkent and Dominiak 2020) including 27 reported from the Oriental region (Table 1). Before this study, four species of the ornatus group have been reported from India: C. peliliouensis Tokunaga in Tokunaga and Esaki 1936, C. aequalispinus Nandi, Mazumdar & Das Gupta, 2013, C. fuscitibialis Nandi, Mazumdar & Das Gupta, 2013, and C. pateli Nandi, Mazumdar & Das Gupta, 2013. Members of the ornatus group can be recognised by the following characteristics: Eyes usually bare, seldom hairy; contiguous to moderately separated; hind tibial comb with 4 (rarely 5) tibial spines, the one nearest the spur longest; wing with second radial cell usually dark to tip but pale distally in some species; presence of two large sclerotised spermathecae with a vestigial one, sclerotised ring present or absent; male genitalia with well developed apicolateral processes, aedeagus usually with low basal arch and long, tapering, rather blunt distal process; parameres usually fused at bases, the basal portion of each directed laterad with well developed anterior process, the distal portion usually straight, simple and slender with simple pointed tip.

Table 1.

Distribution of the species of ornatus group of the genus Culicoides Latreille reported from the Oriental region.

Sl. No. Name of the species Distribution
1. C. aequalispinus Nandi, Mazumdar & Das Gupta, 2013 India
2. C. circumbasalis Tokunaga, 1959 Indonesia, Malaysia, Papua New Guinea, Philippines, Thailand
3. C. cordiger Macfie, 1934 Australia, Papua New Guinea, Malaysia, Philippines
4. C. corti Causey, 1938 Malaysia, Thailand, Vietnam
5. C. damnosus Delfinado, 1961 Indonesia, Malaysia, Philippines
6. C. flumineus Macfie, 1937 Indonesia, Malaysia, Philippines
7. C. fuscitibialis Nandi, Mazumdar & Das Gupta, 2013 India
8. C. garciai Wirth & Hubert, 1989 Malaysia
9. C. griffithi Wirth & Hubert, 1989 Laos, Thailand
10. C. hewitti Causey, 1938 Malaysia, Philippines, Thailand, Vietnam
11. C. hollandiensis Tokunaga, 1959 Indonesia
12. C. infulatus Delfinado, 1916 Indonesia, Philippines
13. C. cornatus sp. nov. India
14. C. maai Wirth & Hubert, 1989 Malaysia
15. C. mcdowelli Delfinado, 1961 Indonesia, Philippines
16. C. niphanae Wirth & Hubert, 1989 Thailand
17. C. okinawensis Arnaud, 1956 Indonesia, Japan, Laos, Taiwan, Thailand, Vietnam
18. C. palawanensis Delfinado, 1961 Indonesia, Malaysia, Philippines
19. C. pampangensis Delfinado, 1961 Indonesia, Malaysia, Philippines, Sri Lanka, Thailand
20. C. pangkorensis Wirth & Hubert, 1989 Indonesia, Malaysia
21. C. papuensis Tokunaga, 1962 Brunei, Indonesia, Papua New Guinea, Philippines
22. C. pateli Nandi, Mazumdar & Das Gupta, 2013 India
23. C. peliliouensis Tokunaga, in Tokunaga and Esaki 1936 Kiribati, Indonesia, Malaysia, Philippines, Thailand, Vietnam, India
24. C. pileus sp. nov. India
25. C. pongsomiensis Chu, 1986 Cambodia
26. C. ornatus Taylor, 1913 Australia, Papua New Guinea, Indonesia, Malaysia, Singapore
27. C. quatei Wirth & Hubert, 1989 Indonesia, Malaysia

In this paper we describe two new species of the genus Culicoides Latreille belonging to the ornatus species group from the Indian Sundarban Deltaic region and provide a key to the adults of the species of the ornatus group of the Oriental Region.

Materials and methods

Adults of both sexes of Culicoides pileus sp. nov. and C. cornatus sp. nov. were caught using ultraviolet light trap with an 8W UV light operated besides the cow shed adjoining to mangrove forest area in Sundarbans (Fig. 1A–C). The adults were preserved in 70% ethanol. The insects were mounted on glass slides following Wirth and Marston (1968).

Figures 1.

A–C. Collection site. A. Outline map of India; B. Google map of West Bengal (Source: maps.google.com); C. Collection site of Culicoides cornatus sp. nov. and C. pileus sp. nov.

Morphology and terminology of adults follow Brown et al. (2009). The wing venation is after Szadziewski (1996). Measurements are in micrometres (μm), except length and width of wing, which are in millimetres (mm). All measurements are presented as ranges when sample size was more than one, with the mean value in parentheses. The illustrations were made using a compound microscope (Wild Leitz GMBH, Portugal) in combination with an attached camera lucida. The photographs were taken both with a trinocular compound microscope (Wild Leitz GMBH) and a Stereo zoom trinocular microscope (Olympus, model SZX16, Japan). For Scanning Electron Microscopy a Carl Zeiss Sigma 300 FESEM instrument was used.

Type specimens are now in the Entomological collections of the Department of Zoology, University of Burdwan (India) and will be deposited to the National Zoological Collections (NZCI), Kolkata (India) in due course.

Abbreviations of morphological terms used in the text and/or figures: Adult. AR – antennal ratio; SCh – sensilla chaetica; SCo – sensilla coeloconica; P/H – proboscis to head ratio; PR – palpal ratio; CR – costal ratio; WL – wing length; WW – wing width; TRn – tarsal ratio; BUENTD – Burdwan University Entomology Division; NZCI – National Zoological Collections of India.

Taxonomy

Genus Culicoides Latreille, 1809

Subgenus unplaced, ornatus species group

Culicoides cornatus sp. nov.

Figs 2A–H, 3A–E

Type material

Holotype : male, labelled as ‘Holotype Culicoides cornatus Chatterjee, Pal and Hazra, India, West Bengal, South 24 Parganas, Balibazar [22°08'88"N, 88°75'72"E], 16.04.2019, Coll. S. Chatterjee’ (NZCI). Paratypes: 1 male and 3 females, data as holotype (BUENTD).

Diagnosis

Eyes with interfacetal hair, wing with inconspicuous pale marking, pale spot on cell r3 occupying greater than half of the entire cell, tips of veins pale; horn shaped appearance of anterior portion of parameres.

Description

Female (n = 3). Head. Brown, eyes with interfacetal hair (Fig. 3C), separated by distance of 1–2 ommatidia; frontovertex with 29–31 SCh; antenna pale; length ratio of antennal segments (I–XIII): 21–22 (21.5): 10: 10–11 (10.5): 9–10 (9.5): 10: 9–10 (9.5): 9: 10: 20: 24–25 (24.5): 24–25 (24.5): 25: 31–33 (32); AR 1.40–1.39 (1.395); SCo (Fig. 2B) present on antennal segments I–XII; only absent in segment XIII; maxillary palpus (Figs 2A, 3D) pale, hairy; length ratio of palpal segments (I–V): 10: 19: 28: 9: 10; PR 2.15. Palpal segment III moderately swollen with subapically round, shallow sensory pit with numerous capitate sensilla restricted in sensory pit; SCh numbers in palpal segments (I–V): 1: 4: 6: 3: 6. Mandible with 17 teeth. P/H 0.58.

Figures 2.

A–H. Adult male and female of Culicoides cornatus sp. nov. A. Female maxillary palp; B. Female antenna; C. Female legs (femur and tibia); D, Female hind tibial comb; E. Female spermatheca; F. Paramere of male genitalia; G. Aedeagus of male genitalia; H. Male genitalia. Scale bar: 0.05 mm.

Figures 3.

A–E. Adult male and female of Culicoides cornatus sp. nov. A. Female wing (Photograph); B. Female thorax (Photograph); C. Female Eye (SEM Photograph); D. Female maxillary palp (SEM Photograph); E. Female hind tibial comb. (SEM Photograph).

Thorax (Fig. 3B). Brown in colour.

Wing (Fig. 3A). Wing with inconspicuous pale marking; costa moderately long; cell r2 moderately broad with distinct lumen; macrotrichia sparse; wing length 0.90–0.92 (0.91) mm, width 0.44–0.46 (0.45) mm; CR 0.68–0.69 (0.685); second radial cell entirely in dark region; pale spot over r-m cross vein moderately large, extending from vein M1 to costal margin; post stigmatic pale spot obliquely placed with slight medial constriction; cell r3 with distal large pale spot occupying greater than half of cell r3 and broadly touching wing margin; cell M1 with two pale spots, distal one touching wing margin; anal cell with one medially constricted distal pale spot, proximal one extended to pale spot at arculus, ends of veins pale at wing margin.

Leg (Fig. 2C). Brown in colour. Fore femora and tibia dark throughout with proximal small pale region, mid tibia and femora dark throughout; hind femora moderately dark all over and hind tibia with distal pale region; hind tibial comb (Figs 2D, 3E) with 4 spines, one nearest to spur longest, spur tip frayed.

Abdomen. Brown; two large, subequal, roughly rounded functional spermathecae with sclerotised necks, measuring one 55.20–57.50 (55.35) µm by 46.00–48.30 (47.00) µm, another one 52.90–55.20 (54.05) µm by 41.40–43.70 (42.55) µm; both with slender, moderately long neck, rudimentary third one and faintly sclerotised ring present (Fig. 2E).

Male (n = 1). Same as female with the usual sexual differences.

Head. Brown. Eyes with interfacetal hair, separated by distance of 2 ommatidia; frontovertex with 28 SCh; palpus pale, palpal segment III moderately swollen with apical shallow sensory pit; PR 2.5.

Thorax. Dark brown.

Wing. Similar with female except morphometric characters. Distribution of macrotrichia in cells; wing length 0.89 mm, width 0.34 mm.

Leg. Brown in colour, all legs uniformly dark without any pale region; hind tibial comb with 4 spines and nearest to spur longest, spur tip frayed.

Abdomen. Ninth sternum with shallow caudomedial excavation; ventral membrane not speculated; ninth tergum with lateral margin more or less straight.

Genitalia (Fig. 2H). Apicolateral process well developed, moderately elongated, broadly separated caudal margin between them rounded with deep mesal notch; gonocoxite (Fig. 2H) 80.5 µm long, 52.9 µm wide at base, 27.6 µm wide at apex with ventral root poorly developed while dorsal root well developed. Gonostylus (Fig. 2H) 62.1 µm long; 18.4 µm wide at base, 4.6 µm wide at apex, slightly curved, narrowed distally. Aedeagus (Fig. 2G) 62.10 µm long with basal arch low; basal arm short and stout, directed posterolaterad; distal stem stout, tapering distally to blunt, truncated tip; parameres (Fig. 2F) 52.9 µm long, fused very short distance at base anteriorly, basal arm directed anterolaterad with well developed anterior process, anterolateral arm horn shaped, stem tapering near base, simple, filamentous, pointed distally.

Remarks

New species shows similarities with C. aequalispinus and C. fuscitibialis but differs from the former in wing pattern and spine structure of hind tibial comb (second nearest the spur longer in C. aequalispinus). Culicoides fuscitibialis differs from the new species in disposition of some pale spots of wing and structure of third palpal segment. New species shows similarities with C. circumbasalis Tokunaga, 1959 and C. cordiger Macfie, 1934 in wing pattern but differs in many attributes such as eyes with interfacetal hair and pale spots on wing inconspicuous in Culicoides cornatus sp. nov. Culicoides cornatus shows similarities with C. cordiger Macfie, 1934 in wing pattern but differs in attributes like eyes (eyes with interfacetal hair in new species but eyes are bare in C. cordiger), antennal ratio, mandibular teeth number and distribution of SCo on antennal segments. The new species shows similarities with C. corti Causey, 1938 in some characters like eyes with interfacetal hair, disposition of some pale spots on wing but differs in characters like palpal ratio, distribution of SCo, and on antennal segments (SCo are present on I–XII in C. cornatus but SCo on I and XI–XIII in C. corti), P/H ratio, shape of the aedeagus and paramere. Distribution of SCo on antennal segments of Culicoides cornatus are similar with C. damnosus Delfinado, 1961 and C. flumineus Macfie, 1937 but differs in characters like eyes with interfacetal hair, antennal ratio, mandibular teeth, and number and disposition of pale spots on wing. Culicoides cornatus shows similarities with C. palawanensis Delfinado, 1961 in SCo distribution and hairy eyes but differs in disposition of pale spots on wing, shape of the parameres and aedeagus, P/H ratio (much less in C. cornatus), mandibular teeth number (17 in C. cornatus but 11–13 in C. palawanensis), and antennal ratio. Culicoides cornatus also shares similarities with C. papuensis Tokunaga, 1962 in disposition of some pale spots on wing but differs in the presence of interfacetal hair on eyes in Culicoides cornatus (bare in C. papuensis), distribution of SCo on the antennal segments, mandibular teeth number, antennal ratio and the shape of parameres. Culicoides cornatus differs with C. hollandiensis Tokunaga, 1959 in pale marking of wing (inconspicuous pale marking in C. cornatus whereas prominent pale marking present in C. hollandiensis) and shape of the aedeagus (terminally rounded in C. hollandiensis). Culicoides cornatus differs from C. pampangensis Delfinado, 1961 in structure of paramere and pale marking of wing. Culicoides cornatus is different from C. paragarciai Dyce, 1996 in pale marking on wing (pale marking absent in C. paragarciai) and structure of hind tibial comb (hind tibial comb with 5 spines and 2nd from the spur is longest in C. paragarciai whereas 4 spines and 1st from the spur longest in C. cornatus). Culicoides quaterifasciatus Tokunaga, 1959 differs in presence of densely spread macrotrichia on wing and also some pale marking is different from C. cornatus.

Etymology

The name ‘cornatus’ refers to Latinised version of cow horn shaped appearance of anterior portion of parameres.

Distribution and bionomics

The species was collected in adjacent to Indian Sundarbans Deltaic region, a world heritage site (West Bengal state). Adult midges were collected from a cowshed using an ultraviolet light trap in the type locality, situated in the vicinity of Datta River. The type locality is at an altitude of 7.50 m above sea level.

Culicoides pileus sp. nov.

Figs 4A–H, 5A–E

Type material

Holotype : male, labelled as ‘Holotype Culicoides pileus Chatterjee, Pal and Hazra, India, West Bengal, South 24 Parganas, Balibazar [22°08'88"N, 88°75'72"E], 16.04.2019, Coll. S. Chatterjee’ (NZCI). Paratypes 2 males and 5 females, data as holotype (BUENTD).

Diagnosis

Eyes bare; wing with one distal pale spot in cell r3 separated from wing margin; cell m1 with two pale spots, distal one away from wing margin; anal cell with one distal pale spot with slight medial constriction; SCo present on flagellomeres I–VII and IX–XII; parameres basally fused, cap shaped basal knob, mid portion wide, distally slender, abruptly bent laterad with pointed end.

Description. Female (n = 5). Head. Brown. Eyes bare (Fig. 5C), separated by distance of 1–2 ommatidia; frontovertex with 33–37 SCh; antenna pale; length ratio of antennal segments (I–XIII): 12–15 (13.50): 9–10 (9.50): 10–11 (10.5): 10–11 (10.50): 10–11 (10.5): 10: 11: 10–11 (10.50): 17–19 (18): 17–19 (18): 19–21 (20): 21–22 (21.5): 29–30 (29.50); AR 1.20–1.23 (1.21); SCo (Fig. 4B) present on antennal segments I–VII, IX–XII; maxillary palpus (Fig. 4A) pale, hairy; length ratio of palpal segments (I–V): 8–9 (8.50): 20–25 (22.5): 25–28 (26.5): 7–9 (8): 9–10 (9.50); PR 2.15–2.27 (2.21); palpal segment III moderately swollen with subapical round shallow sensory pit with 22–26 (24) capitate sensilla restricted in sensory pit; SCh numbers in palpal segments (I–V): 0: 3: 8: 2: 6. Mandible (Fig. 5E) with 16–17 teeth. P/H 0.85–0.89 (0.87).

Figures 4.

A–H. Adult male and female of Culicoides pileus sp. nov. A. Female maxillary palp; B. Female antenna; C. Female legs (femur and tibia); D. Female hind tibial comb; E. Female spermatheca; F. Paramere of male genitalia; G. Aedeagus of male genitalia; H. Male genitalia. Scale bar: 0.05 mm.

Figures 5.

A–E. Adult male and female of Culicoides pileus sp. nov. A. Female wing (Photograph); B. Female thorax (Photograph); C. Female Eye (SEM Photograph); D. Female hind tibial comb (SEM Photograph); E. Female mandible (SEM Photograph).

Thorax (Fig. 5B). Brown in colour.

Wing. Wing pattern as in figure 5A, costa moderately long; cell r2 moderately broad with distinct lumen, macrotrichia sparse, arranged from middle to distal most portion of wing; wing length 0.77–0.80 (0.78) mm; width 0.38–0.42 (0.40) mm; CR 0.64–0.65 (0.645). wing spots moderately distinct, second radial cell completely in dark region; pale spot over r-m cross vein moderately large, extending from vein M1 to costal margin; post stigmatic pale spot obliquely placed with slight medial constriction; cell r3 with distal large pale spot away from wing margin; cell M1 with two pale spots, distal one separated from wing margin; cell m2 with narrow pale streak connecting pale spot at basal arculus, pale spot behind medial fork and distal pale spot; distal pale spot touching wing margin; cell cua1 with moderately large, roughly round pale spot touching CuA1 vein and broadly touching wing margin; anal cell with one medially constricted distal pale spot, proximal one extended to pale spot at arculus.

Leg (Fig. 4C). Brown in colour. Fore and mid femora pale throughout, fore and mid tibia with proximal pale region; hind femora moderately dark throughout and hind tibia also with proximal pale region; hind tibial comb with 4 spines, one nearest to spur longest, spur tip frayed (Figs 4D, 5D).

Abdomen. Brown; two large subequal roughly rounded functional spermathecae with sclerotised necks, measuring one 46.00–50.60 (48) µm by 41.40–43.70 (42.55) µm, another one 43.70–48.30 (46.00) µm by 39.10–41.40 (40.25) µm; both with slender, moderately long neck, rudimentary third one, and faintly sclerotised ring present (Fig. 4E).

Male (n = 3). Same as female with the usual sexual differences.

Head. Brown. Eyes bare, separated by distance of 1–2 ommatidia, frontovertex with 18–21 SCh. Palpus pale; palpal segment III moderately swollen with apical shallow sensory pit; PR 2.00.

Thorax. Dark brown.

Wing. Similar with female except distribution of macrotrichia in cells; macrotrichia sparse, mostly arranged on distal one third portion of wing; wing length 0.81–0.83 (0.82) mm, width 0.36–0.38 (0.37) mm.

Leg. Light brown in colour, hind tibial comb with 4 spines and nearest to spur longest, spur tip frayed.

Abdomen. Ninth sternum with shallow caudomedial excavation; ventral membrane not speculated; ninth tergum with lateral margin more or less straight.

Genitalia (Fig. 4H). Apicolateral process well developed, elongated, broadly separated caudal margin between them rounded with slight mesal notch; gonocoxite (Fig. 4H) 69.00–71.3 (70.15) µm long, 46.00–48.30 (47.15) µm wide at base, 25.30–27.60 (26.45) µm wide at apex with ventral root poorly developed and dorsal root well developed. Gonostylus 59.80–64.4(62.1) µm long; 16.10–18.40 (17.25) wide at base, 6.9 µm wide at apex slightly curved, narrowed distally with blunt mesally toothed tip. Aedeagus (Fig. 4G) 62.10–64.40 (63.25) µm long with basal arch low, less than one sixth of total length; basal arm short and stout, directed posterolaterad; mid portion slender to moderately broad with bluntly rounded tip. Parameres (Fig. 4F) 48.30–50.6 (49.45) µm long, fused short distance at base anteriorly, basal arm directed anterolaterad with well developed cap shaped anterior process, mid portion wide, distally slender, abruptly bent laterad with pointed end.

Remarks

New species shows similarities with C. aequalispinus in bare eyes and mandibular teeth number but differs in attributes like distribution of SCo on antennal segments, and presence of two equal length spines nearest to the spur in C. aequalispinus. The new species shares a few similarities with C. peliliouensis Tokunaga in Tokunaga and Esaki 1936 like bare eyes, disposition of some pale spots on wing but differs in characters like distribution of SCo on antennal segments (SCo present on I, V–VII and IX–XII in C. peliliouensis but in C. pileus sp. nov. these are on I–VII and IX–XII), pale spot on cell r3 broadly touching the wing margin but in new species it is separated by dark region; pale spot over r-m cross vein is different in shape, post stigmatic pale spot medially constricted in C. pileus but not in C. peliliouensis. Culicoides pileus shows some similarities with C. circumbasalis Tokunaga, 1959 and C. ornatus Taylor, 1913 but differs in characters like distal pale spot in anal cell of wing (two separate distal pale spots present in both C. circumbasalis and C. ornatus but in C. pileus a single pale spot present with little medially constricted), cell r3 with three pale spots and most distal one touching the wing margin in C. circumbasalis but two in C. pileus sp. nov. and most distal one away from the wing margin. It is quite similar in some attributes with C. cordiger Macfie, 1934 but differs in distribution of SCo on antennal segments (SCo are present on antennal segments I–XIII in C. cordiger) and mandibular teeth number (7–12 in C. cordiger but 16–17 in C. pileus). Culicoides pileus differs from C. damnosus Delfinado, 1961 and C. quatei Wirth & Hubert, 1989 in the shape of pale spot over r-m cross vein and distribution of SCo on antennal segments. It shares similarities with C. mcdowelli Delfinado, 1961 but differs in the shape of pale spot over r-m cross vein, distal pale spot on cell r3 (touching the wing margin in C. mcdowelli) and mandibular teeth number (11–13 in C. mcdowelli). It also shows some similarities with C. hollandiensis Tokunaga, 1959 in wing pattern but pale spot is absent at the base of CuA1 in C. pileus and anal cell with two separated distal pale spots in C. hollandiensis. Culicoides pileus differs from C. hollandiensis in pale marking of wing (anal cell with two separate distal pale spots in C. hollandiensis) and shape of the aedeagus. Culicoides pileus differs from C. pampangensis Delfinado, 1961 in structure of paramere and pale marking of wing (cell r3 with distal pale spot not prominent in C. pampangensis Delfinado). Culicoides paragarciai Dyce, 1996 differs from C. pileus in pale marking on wing (pale marking absent in C. paragarciai) and structure of hind tibial comb (hind tibial comb with 5 spines and 2nd from the spur is longest in C. paragarciai whereas 4 spines and 1st from the spur longest in C. cornatus).

Etymology

The name ‘pileus’ refers to Latinised version of cap shaped basal knob of parameres.

Distribution and bionomics

The species was collected from Sundarbans Mangrove Forest in India (West Bengal state). Adult midges were collected from a cowshed using an ultraviolet light trap in the type locality situated in the vicinity of Datta River. The type locality is at an altitude of 7.50 m above sea level.

An inventory of ornatus group of the genus Culicoides Latreille from the Oriental region

Distribution of Oriental species of ornatus group has been presented in Table 1 and Fig. 6.

Figure 6.

Distribution of the Oriental species of ornatus group of the genus Culicoides Latreille. The number(s) in the bubbles of the respective countries depicts the species (Sl. nos.) presented in Table 1.

A key to the ornatus group of the genus Culicoides Latreille from the Oriental region

1 Wing with second radial cell partially included in pale spot distally (a) C. quaterifasciatus Tokunaga, 1959
Wing with second radial cell almost fully included in dark spot (b) 2
1 Distal pale spot in cell r3 with medial constriction in wing (a) C. hollandiensis Tokunaga, 1959
Distal pale spot in cell r3 without medial constriction in wing 3
2 Eyes with interfacetal hair 4
Eyes bare 7
3 Mandible with 5–6 vestigial teeth C. corti Causey, 1938
Mandible with 10–17 teeth 5
4 Pale spots on wing conspicuous C. griffithi Wirth & Hubert, 1989
Pale spots on wing inconspicuous 6
5 Mandible with 12 teeth C. palawanensis Delfinado, 1961
Mandible with 17 teeth C. cornatus sp. nov.
6 Hind tibial comb with 5 spines 8
Hind tibial comb with 4 spines 11
7 Wing without pale marking 9
Wing with pale and dark spots 10
8 Nearest spine from spur longest in hind tibial comb C. flumineus Macfie, 1937
Second nearest spine from spur longest in hind tibial comb C. paragarciai Dyce, 1996
9 Smaller sized species; darker legs; spermathecae smaller C. pangkorensis Wirth & Hubert, 1989
Large sized species; paler legs; spermathecae comparatively larger C. papuensis Tokunaga, 1962
10 Second spine from spur of hind tibial comb longest 12
First spine from spur of hind tibial comb longest or both first and second spines with same length 14
11 Wing without any pale spot C. garciai Wirth & Hubert, 1989
Two pale spots present on wing 13
12 Parameres distally becoming hyaline and curving ventrolaterad with blunt tip C. okinawensis Arnaud, 1956
Parameres with filamentous distal end C. pateli Nandi, Mazumdar & Das Gupta, 2013
13 First and second spines from spur of hind tibial comb same in length C. aequalispinus Nandi, Mazumdar & Das Gupta, 2013
First spine from spur of hind tibial comb longest 15
14 SCo present on terminal antennal segment 16
SCo absent on terminal antennal segment 17
15 Distal stem of aedeagus short and slender with a little expanded tip C. cordiger Macfie, 1934
Distal stem comparatively long with tapering to slender tip C. maai Wirth & Hubert, 1989
16 Anal cell of wing with two separate distal pale spots 18
Anal cell of wing with one distal pale spot 23
17 Distal most pale spot of cell r3 touching wing margin 19
Distal most pale spot of cell r3 separated from wing margin 22
18 Cell r3 with two distal pale spots C. circumbasalis Tokunaga, 1959
Cell r3 with one distal pale spot 20
19 Third palpal segment with a moderately broad, shallow and round sensory pit C. niphanae Wirth & Hubert, 1989
Third palpal segment with irregular sensory area, sometimes subdivided into one or several irregular pits 21
20 Haltere pale C. peliliouensis Tokunaga in Tokunaga and Esaki 1936
Haltere comparatively dark C. pongsomiensis Chu, 1986
21 SCo present on antennal segments I, IX–XII, sometimes also on II, III, IV and VI C. ornatus Taylor, 1913
SCo present on antennal segments I–XII C. quatei Wirth & Hubert, 1989
22 Anal cell of wing with one round distal pale spot 24
Anal cell of wing with one medially constricted distal pale spot 25
23 Anal cell of wing with round distal pale spot away from wing margin (a) C. fuscitibialis Nandi, Mazumdar & Das Gupta, 2013
Anal cell of wing with round distal pale spot touching wing margin (b) C. pampangensis Delfinado, 1961
24 Distal most pale spot of cell r3 touching wing margin (a) C. mcdowelli Delfinado, 1961
Distal most pale spot of cell r3 separated from wing margin 26
25 SCo present on antennal segments I–XII 27
SCo absent on one or more antennal segments in between I–XII 28
26 Vestigial third spermatheca and sclerotised ring present C. hewitti Causey, 1938
Vestigial third spermatheca and sclerotised ring absent C. damnosus Delfinado, 1961
27 Distal pale spot on cell m1 separated from wing margin C. pileus sp. nov.
Distal pale spot on cell m1 touching wing margin C. infulatus Delfinado, 1916

Acknowledgements

We convey our sincere thanks to Dr P. K. Chaudhuri, former Professor, Department of Zoology, The University of Burdwan, for critically going through the manuscript and rendering valuable suggestions. The authors thank Mr. Basudev Das, Senior Technical Assistant, University Science Instrumentation Centre (USIC), The University of Burdwan, for the fabrication and maintenance of the ultraviolet light trap. Authors are thankful to Dr. Shubhranil Brahma for sorting of specimens and slide preparation.The research is supported by West Bengal Biodiversity Board, Government of West Bengal, India [number 703/3K(Bio)–1/2016]. The authors are thankful to the Head, DST-FIST sponsored Department of Zoology, University of Burdwan and Ministry of Science and Technology (DST-PURSE Programme), New Delhi, India for providing research facilities. We are grateful to the Department of Forest, Govt. of West Bengal, for giving permission to carry out the fieldwork.

References

  • Arnaud P (1956) The heleid genus Culicoides in Japan, Korea and Ryukyu Islands (Insecta: Diptera). Microentomology 21: 84–207.
  • Borkent A (2005) Ceratopogonidae. In: Marquart WC (Ed.) Biology of Disease Vectors, 2nd edn. , Elsevier Press, Amsterdam, 785 pp.
  • Borkent A (2014) The pupae of the biting midges of the world (Diptera: Ceratopogonidae), with a generic key and analysis of the phylogenetic relationships between genera. Zootaxa 3879(1): 1–327. https://doi.org/10.11646/zootaxa.3879.1.1
  • Brown BV, Borkent A, Cumming JM, Wood DM, Woodley NE, Zumbado MA (2009) Manual of Central American Diptera. NRC Research Press, Ottawa (Ontario, Canada), 714 pp.
  • Chatterjee S, Brahma S, Hazra N (2020) Two new species of Culicoides Latreille (Diptera: Ceratopogonidae) from the Gangetic Plains of West Bengal, India with a key to the Indian species. Oriental Insects 55(3): 305–345. https://doi.org/10.1080/00305316.2020.1775718
  • Chu FI (1986) The biting midges of Cambodia, with descriptions of two new species (Diptera: Ceratopogonidae) Entomotaxonomia 8: 251–261. [in Chinese, English summary]
  • Harrup LE, Laban S, Purse BV, Reddy YK, Reddy YN, Byregowda SM, Kumar N, Purushotham KM, Kowalli S, Prasad M, Bettis AA, De Keyser R, Logan J, Garros C, Gopurenko D, Bellis G, Labuschagne K, Mathieu B, Carpenter S (2016) DNA barcoding and surveillance sampling strategies for Culicoides biting midges (Diptera: Ceratopogonidae) in southern India. Parasites and Vectors 9: e461. https://doi.org/10.1186/s13071-016-1722-z
  • Ilango K (2006) Bluetongue virus outbreak in Tamil Nadu, southern India: Need to study the Indian biting midge vectors, Culicoides Latreille (Diptera: Ceratopogonidae). Current Science 90(2): 163–167.
  • Jamnback H (1965) The Culicoides of New York state (Diptera: Ceratopogonidae). New York State Museum and Science Service Bulletin 399: viii + 154.
  • Kettle DS, Lawson JWH (1952) The early stages of British biting midges Culicoides Latreille (Diptera: Ceratopogonidae) and allied genera. Bulletin of Entomological Research 43(3): 421–467. https://doi.org/10.1017/S000748530002945X
  • Nandi M, Mazumdar A, Das Gupta SK (2013) Three new species of the Culicoides ornatus group. Studia Dipterologica 20(2): 223–231.
  • Prasad G, Sreenivasulu D, Singh KP, Mertens PPC, Maan S (2009) Bluetongue in the Indian Subcontinent. In: Mellor PS, Baylis M, Mertens PPC (Eds) Bluetongue. Elsevier Academic Press, London, 167–195. https://doi.org/10.1016/B978-012369368-6.50012-5
  • Shults P, Borkent A (2018) Pupae of the Nearctic species of Culicoides Latreille subgenus Monoculicoides Khalaf (Diptera: Ceratopogonidae). Zootaxa 4504(4): 451–472. https://doi.org/10.11646/zootaxa.4504.4.1
  • Szadziewski R (1996) Biting midges from Lower Cretaceous amber of Lebanon and Upper Creatceous Siberian amber of Taimyr (Diptera, Ceratopogonidae). Studia Dipterologica 3: 23–86.
  • Taylor FH (1913) Report of the entomologist. Report of the Australian Institute of Tropical Medicine 1911: 49–74.
  • Tokunaga M (1959) New Guinea biting midges (Diptera: Ceratopogonidae). Pacific Insects 1: 177–314.
  • Tokunaga M (1962) Biting midges of the genus Culicoides from New Guinea (Diptera: Ceratopogonidae). Pacific Insects 4: 457–516.
  • Tokunaga M, Esaki T (1936) A new biting midge from the Palau Islands, with its biological notes. Mushi 9: 55–58.
  • Wirth WW, Hubert AA (1989) The Culicoides of Southeast Asia (Diptera: Ceratopogonidae). Memoirs of the American Entomological Institute 44: 1–508.
  • Wirth WW, Marston N (1968) A method for mounting small insects on microscope slides in Canada balsam. Annals of the Entomological Society of America 61(3): 683–684. https://doi.org/10.1093/aesa/61.3.783
